Spun Bonded Filter Cartridge
Product Description:-
Spun Bonded Filter Cartridges are made from 100% polypropylene fibers that are spun and thermally bonded to form a true gradient depth filtration structure. The unique design provides superior particle retention, high dirt-holding capacity, and long service life. These cartridges are free from binders, adhesives, and surfactants—ensuring purity and chemical compatibility.
| Parameter | Details |
|---|---|
| Product Name | Spun Bonded Filter Cartridge |
| Material | 100% Polypropylene |
| Construction | Multi-layered depth structure (graded density) |
| Micron Rating | 1 µm to 100 µm |
| Length Options | 10", 20", 30", 40" |
| Outer Diameter | 63 mm (Standard) |
| Inner Diameter | 28 mm (Standard) |
| Operating Temperature | Up to 60°C |
| Applications | Pre-filtration, RO systems, Chemicals, Food & Beverage, Pharmaceuticals |
| Features | High dirt holding capacity, Long service life, No media migration, Non-toxic |
✅ Applications of Spun Bonded Filter Cartridge
-
✔️ RO Pre-filtration – Ideal for removing sediment before reverse osmosis membranes
-
✔️ Drinking Water Filtration – Used in domestic, commercial, and industrial water systems
-
✔️ Pharmaceuticals – Filtration of solvents, chemicals, and process liquids
-
✔️ Food & Beverage Industry – Clarification of water, beverages, syrups, and edible oils
-
✔️ Electronics Industry – Used in DI (Deionized) water and sensitive chemical filtration
-
✔️ Chemical Processing – Effective for filtering acids, alkalis, and corrosive liquids
